Engineered for Safety, Ergonomics, and Reliability
The Albion 38NX06228SLFBKTO swivel caster is built to improve workplace safety while delivering unmatched mobility for heavy-duty equipment and is the ideal upgrade when utilizing tough forged steel, cast iron, or other metal wheels. This ergonomic and completely maintenance-free caster is ANSI ICWM tested and backed by a 3-year premium warranty, ensuring lasting performance in the most demanding industrial environments.
Key Safety & Ergonomic Advantages
-
USA Maintenance-Free Rig – Sealed precision ball bearings in both swivel section and wheel eliminate the need for lubrication for the life of the caster.
-
Effortless Mobility – Reduced push/pull forces help minimize operator fatigue and workplace injuries.
-
Extended Lead Design – Allows smooth caster alignment, easier steering, and reduced chatter in towed or high-speed applications.
-
Toe Guard Protection – Helps shield operators’ feet from accidental impacts and keeps debris clear from the wheel path.
-
Positive Face Brake – Easy-to-engage brake locks the wheel securely during loading, unloading, or stationary use.
-
4-Position Swivel Lock – Converts the swivel into a rigid caster when needed for precise directional control.
Premium Heavy-Duty Nylon Wheel
-
Material: Trionix high-impact polymer nylon (78-82 Shore D hardness)
-
Performance: Matches the load capacity of metal wheels but rolls quieter and protects floors, plus it is maintenance-free.
-
Chemical & Moisture Resistance: Withstands corrosion, water, and most chemicals.
-
Temperature Range: -30°F to 220°F for versatile use in extreme conditions.
-
Profile: Slight crown tread enhances maneuverability while maintaining stability.
Specifications
-
Wheel Size: 6" diameter x 2" wide heavy-duty nylon
-
Capacity: 2,160 lbs dynamic load per caster
-
Top Plate Size: 6-1/4" x 4-1/2"
-
Brake Type: Face brake
-
Swivel Lock: 4-position
-
Toe Guard: Integrated into legs
-
Rig Type: Albion ergonomic extended-lead swivel rig
-
Finish: Zinc plated for corrosion resistance
-
Bearings: Sealed precision ball bearings (wheel and swivel)
-
Warranty: 3 years
-
Testing: ANSI ICWM tested for safety and performance
Ideal Applications
-
Industrial carts and dollies
-
High-capacity warehouse equipment
-
Bulk material handling trucks
-
Waste disposal and transport carts
-
Any operation prioritizing ergonomics and operator safety
Need a rigid, brake-free, or alternative wheel version?
This premium Albion ergonomic series is readily available in multiple configurations to meet your exact requirements—contact us for options and volume pricing.
